Hoist Control Cable 2×1.0 mm² + 4×2×24AWG, Steel Support, PVC, 300/500 V

Name: Hoist Control Cable 2×1.0 mm² + 4×2×24AWG, Steel Support, PVC, 300/500 V
Brand: PAIDE

Elevator Traveling Cables · Industrial Automation

Hoist and crane control cable with two 1.0 mm² cores and four 24AWG pairs, jute filler, torsion-free steel support wires, PVC sheath, bending radius 20D.

Request pricing → Email engineering

Built to project order: conductor cross-section and core count, shield type, sheath colour, length and print legend can all be adapted to the working conditions; technical parameters are subject to the specification document confirmed by both parties.

Product introduction

Applications:

Hoist cable, also called electric hoist control cable, is widely used indoors in dry or damp conditions for installations with forced guidance and non-continuous motion, such as electric hoists, travelling cranes and inspection equipment, self-supporting shafts or inclined racks, cranes and ports. The outer sheath can be customised to different weather conditions and applications, so the product can also be used in the open air.

Construction:

- 2 cores 1.0 mm² (17AWG)

- 4 twisted pairs 24AWG

Conductor: flexible stranded oxygen-free copper according to DIN VDE 0295 class 5

Insulation: high-quality PVC compound

Insulation colours: cores coded by different colours or with a yellow-green core.

Filler: high-quality jute tensile rope

Strength member: single or twin torsion-free self-supporting steel wire.

Outer sheath: PVC

Colour: black

Rated voltage: 300/500 V, 450/750 V

Test voltage: 3000 V
