Underwater Electric Cable 2×1.0 mm² Tinned Copper PUR

Name: Underwater Electric Cable 2×1.0 mm² Tinned Copper PUR
Brand: PAIDE

Underwater Power Cables · Marine & Subsea

Two-core underwater power cable, 2 × 1.0 mm² tinned copper strands, polyethylene insulation and PUR sheath, 5.9 mm outer diameter, -30 °C to +105 °C.

Request pricing → Email engineering

Customisation available per project: conductor cross-section and core count, shielding type, sheath colour, length and print marking can all be adapted to the operating conditions; technical parameters are subject to the specification document confirmed by both parties.

Product overview

Applications:

Power supply for underwater equipment.

Construction:

- 2 × 1.0 mm²

Conductor: tinned copper strands

Insulation: polyethylene

Outer sheath: PUR

Colour: black

Outer diameter: 5.9 mm

Temperature rating: -30 °C to +105 °C

Polyurethane cables are referred to as PUR cables; they are halogen-free and flame retardant, with higher mechanical and chemical resistance, which makes them suitable for harsh environments.

Our underwater series uses polyurethane as its sheath material, combining strong performance with the flexibility needed for underwater applications involving frequent or continuous bending.

If no standard cable meets your application requirements, we can also build a cable to your full specification.
