PDK81601 2x0.5 + 2SMF-500KG Neutrally Buoyant Optoelectric Cable
Watertight Optoelectric Cables · Marine & Subsea
Neutrally buoyant optoelectric cable with 2x0.5 mm² power cores and two G657A2 single-mode fibers, Kevlar member rated 500 kg, 10.5 mm OD.
Product introduction
Applications: ROV and AUV systems.
Model: PDK81601-2x0.5+2 SMF-500KG
Cable construction:
- 2 cores × 0.5 mm²
for power supply
- 2 single-mode fibers for signal and video transmission
Fiber: G657A2 single-mode
Strength member: Kevlar filler (500 kg)
Sheath: PUR foam
Outer sheath color: yellow
Outer diameter: 10.5 mm
Temperature range: -30 °C to 105 °C
Properties: oil resistant, flame retardant, hydrolysis resistant, anti-bacterial, UV resistant.
The subsea ROV cable is one of our typical cable products. We can customize different sizes and different types to each customer's requirements.
