PDK81601-2×0.5 300 kg Neutrally Buoyant ROV Cable

Name: PDK81601-2×0.5 300 kg Neutrally Buoyant ROV Cable
Brand: PAIDE

Zero-Buoyancy Cables · Marine & Subsea

Two-core 0.5 mm² power cable for ROV and AUV systems with a 300 kg aramid strength member, foam PUR sheath, 8.0 mm diameter, -30 to 105 ℃.

Request pricing → Email engineering

Custom engineering is available: conductor cross-section and core count, shielding type, sheath color, length and print marking can all be adapted to the operating conditions; technical parameters are subject to the specification document confirmed by both parties.

Product overview

Applications: ROV and AUV systems.

Model: PDK81601-2×0.5-300KG

Cable construction:

- 2 cores 0.5 mm²

for power supply

Strength member: aramid filler (300 kg) + cotton

Sheath: PUR foam

Jacket color: green

Outer diameter: 8.0 mm

Temperature range: -30℃~105℃

Properties: oil resistant, flame retardant, hydrolysis resistant, antibacterial, UV resistant.

The subsea ROV cable is one of our typical cable products. We can customize different sizes and different types according to each customer's requirements.
