PDK81601-3x0.75+STP CAT6 Zero-Buoyancy ROV Tether - 14.8 mm, 200 kg

Name: PDK81601-3x0.75+STP CAT6 Zero-Buoyancy ROV Tether - 14.8 mm, 200 kg
Brand: PAIDE

Zero-Buoyancy Cables · Marine & Subsea

Zero-buoyancy ROV tether with 3x0.75 mm2 (19AWG) power cores and 4 pairs of 0.2 mm2 (24AWG) data, Kevlar strength member, 14.8 mm OD, 200 kg.

Request pricing → Email engineering

Customized per project: conductor cross-section and core count, shield type, sheath color, length and print marking can all be adapted to the operating conditions; technical parameters are subject to the specification document confirmed by both parties.

Product description

Application fields

Ø Offshore oil and gas

❖ Renewable energy subsea systems

Ø Offshore equipment systems

ROV and AUV systems

Ø Underwater cameras

❖ Diving equipment systems

Model: PDK81601-3x0.75+STP CAT6-200kg

Cable construction:

- 3 cores x 0.75 mm²

(19AWG)

- 4 pairs x 0.2 mm²

(24AWG)

Insulation: polyethylene

Strength member: Kevlar fill (200 kg)

Fillers: Kevlar plus water-blocking yarn

Network shield: tinned copper braid plus aluminium foil

Sheath: foamed PUR

Outer sheath color: yellow

Outer diameter: 14.8 mm

Minimum bending radius: 10D

Temperature range: -30 C to +105 C

Features: oil resistance, flame retardance, hydrolysis resistance, resistance to bacteria and UV.

This cable is custom-built to customer requirements. Floating subsea cables are among our typical cable projects, and we can customize different sizes and types to each customer's requirements.
