PDK41302-2x20AWG+1x2x28AWG+1SMF Tethered Drone Cable - 1000 VDC, 5-7 A

Product description

The cable is a hybrid power and fiber optic cable for tethered drones. It is a high-performance hybrid cable designed for demanding drone applications that need power supply and high-speed data transmission at the same time. Durability and reliability were built in from the start, combining robust electrical conductors with a single-mode fiber to ensure uninterrupted operation in mission-critical environments.

Cable construction:

1. Dual power conductors (2x20AWG):

- Heavy-duty 20AWG copper conductors provide stable power transfer, extend flight time and support continuous drone operation.

- Well suited to high-power drones on long-endurance missions.

2. Twisted pair (1x2x28AWG):

- The dual 28AWG twisted pair maintains reliable signal integrity for control and telemetry data.

3. Integrated single-mode fiber (1SMF):

- The single-mode fiber core supports very high speed, low-latency data transmission, for example HD video and real-time sensor data.

- Supports long-distance communication with minimal signal loss.

4. Rugged construction:

- A high-strength fiber braided sheath, multilayer shielding and an abrasion-resistant sheath (for example TPU/PVC) protect against harsh environments, UV exposure and chemical attack.

- A lightweight, flexible design minimizes drag while maintaining durability.

5. Customizable length:

- Standard or custom lengths are available to meet specific mission requirements.

Technical specifications:

- Power conductors: 2x20AWG, stranded silver-plated copper, rated voltage 1000 VDC, rated current 5-7 A

- Signal conductors: 1x2x28AWG, stranded silver-plated copper.

- Fiber core: 1xSMF (9/125 um), G657A2, bend-insensitive fiber.

- Sheath material: high-strength aerospace fiber.

- Temperature range: -40 C to +150 C.

Applications:

- Surveillance and security: real-time HD video streaming for border patrol or incident monitoring.

- Telecommunications: persistent aerial communication relay.

- Industrial inspection: inspection of power lines, wind turbines or infrastructure.

- Public safety: emergency response and disaster recovery operations.

Why choose our cable?

Our tethered drone cable integrates power, signal and fiber into a single lightweight solution, eliminating the need for multiple cables. The hybrid design ensures seamless performance under extreme conditions, making it a common choice for professionals seeking reliability and efficiency.

We also offer customization.

Customize your cable solution now. Contact our team for technical specifications, pricing or OEM/ODM enquiries.
